CLZⅡ系列船用立式自吸離心泵
概述
CLZⅡ系列船用立式自吸離心泵具有體積小、重量輕、自吸性能好、效率高、安裝使用方便等特點，其關鍵技術獲國家專利。適用于各種船舶作艙底泵、壓載泵、冷卻泵和消防泵及其它裝置配套使用。輸送介質溫度不高于80℃。泵的進、出口法蘭符合GB9113.3（PN=1.6MPa）和GB2505（PN=1.6MPa）標準。
型號示例和說明
表1
| 型號 |
電壓380伏 380V 頻率50Hz 50Hz |
||||||
|---|---|---|---|---|---|---|---|
|
泵的主要性能參數 |
|||||||
| 流量 m3/h | 揚程 m | 轉速 r/min | 汽蝕余量 m | 軸功率 kW | 配用功率 kW | 單泵重量 Kg | |
| 40CLZⅡ-2 | 5 | 60 | 2900 | 3.5 | 4.3 | 5.5 | |
| 40CLZⅡ-2A | 4 | 54 | 3.5 | 3.1 | 5.5 | ||
| 40CLZⅡ-2B | 4 | 38 | 3.5 | 2.2 | 4 | ||
| 50CLZⅡ-4.5 | 12.5 | 32 | 4 | 2.7 | 4 | ||
| 50CLZⅡ-4.5A | 11.2 | 26 | 4 | 1.93 | 3 | ||
| 50CLZⅡ-4.5B | 10 | 28 | 4 | 1.86 | 3 | ||
| 50CLZⅡ-4.5C | 10 | 20.5 | 4.5 | 1.33 | 2.2 | ||
| 50CLZⅡ-6 | 20 | 32 | 4 | 3.6 | 5.5 | ||
| 50CLZⅡ-6A | 17 | 28 | 4 | 2.64 | 4 | ||
| 50CLZⅡ-9 | 27 | 14.5 | 4 | 1.87 | 3 | ||
| 50CLZⅡ-9A | 21 | 12 | 4 | 1.25 | 2.2 | ||
| 50CLZⅡ-7 | 12.5 | 20 | 4 | 1.33 | 2.2 | ||
| 50CLZⅡ-7A | 10 | 17 | 4 | 0.91 | 1.5 | ||
| 50CLZⅡ-7B | 10 | 14 | 4 | 0.76 | 1.5 | ||
| 50CLZⅡ-3 | 12.5 | 50 | 4 | 4.9 | 7.5 | ||
| 50CLZⅡ-3A | 10 | 45 | 4 | 3.5 | 5.5 | ||
| 50CLZⅡ-3B | 10 | 32 | 4 | 2.5 | 4 | ||
| 50CLZⅡ-4 | 20 | 50 | 4 | 6.5 | 7.5 | ||
| 50CLZⅡ-4A | 17 | 46 | 4 | 5.1 | 7.5 | ||
| 50CLZⅡ-4B | 17 | 36 | 4 | 4 | 5.5 | ||
| 65CLZⅡ-9 | 25 | 20 | 4 | 2.3 | 3 | ||
| 65CLZⅡ-9A | 21 | 17 | 4 | 1.62 | 2.2 | ||
| 65CLZⅡ-6 | 25 | 32 | 4 | 4.2 | 5.5 | ||
| 65CLZⅡ-6A | 23 | 27.1 | 4 | 3.3 | 5.5 | ||
| 65CLZⅡ-6B | 21 | 28 | 4 | 3.1 | 4 | ||
| 65CLZⅡ-5 | 25 | 45 | 4 | 6.52 | 7.5 | ||
| 型號 |
電壓380伏 380V 頻率50Hz 50Hz |
||||||
|---|---|---|---|---|---|---|---|
|
泵的主要性能參數 |
|||||||
| 流量 m3/h | 揚程 m | 轉速 r/min | 汽蝕余量 m | 軸功率 kW | 配用功率 kW | 單泵重量 Kg | |
| 100CLZⅡ-17A | 72 | 18 | 2900 | 4.5 | 5.8 | 7.5 | |
| 100CLZⅡ-12 | 80 | 32 | 4.8 | 10.75 | 15 | ||
| 100CLZⅡ-12A | 72 | 28 | 4.8 | 8.6 | 11 | ||
| 100CLZⅡ-8 | 80 | 50 | 4.8 | 17.9 | 22 | ||
| 100CLZⅡ-8A | 72 | 46 | 4.8 | 15.3 | 18.5 | ||
| 100CLZⅡ-6 | 80 | 80 | 5 | 32.9 | 37 | ||
| 100CLZⅡ-6A | 72 | 75 | 5 | 28.8 | 37 | ||
| 100CLZⅡ-18.5 | 100 | 20 | 5 | 8.25 | 11 | ||
| 100CLZⅡ-18.5A | 95 | 18 | 5 | 7.3 | 11 | ||
| 100CLZⅡ-13 | 100 | 32 | 5 | 12.5 | 18.5 | ||
| 100CLZⅡ-13A | 95 | 28 | 5 | 10.7 | 15 | ||
| 100CLZⅡ-9 | 100 | 50 | 5 | 22 | 30 | ||
| 100CLZⅡ-9A | 95 | 45 | 5 | 19.4 | 30 | ||
| 100CLZⅡ-6.5 | 100 | 80 | 5 | 36.3 | 45 | ||
| 100CLZⅡ-6.5A | 95 | 75 | 5 | 33.44 | 45 | ||
| 100CLZⅡ-5 | 100 | 120 | 5 | 65.33 | 75 | ||
| 100CLZⅡ-5A | 95 | 110 | 55 | 58.06 | 75 | ||
| 100CLZⅡ-5B | 90 | 97 | 5 | 48.5 | 55 | ||
| 125CLZⅡ-5 | 120 | 120 | 5 | 67.6 | 90 | ||
| 125CLZⅡ-5A | 114 | 108 | 5 | 57.8 | 75 | ||
| 125CLZⅡ-5B | 108 | 97 | 5 | 50 | 75 | ||
| 125CLZⅡ-23 | 160 | 20 | 5.2 | 14.1 | 18.5 | ||
| 125CLZⅡ-16.5 | 160 | 32 | 5.2 | 21.1 | 30 | ||
| 125CLZⅡ-16.5A | 150 | 28 | 5.2 | 17.9 | 22 | ||
| 125CLZⅡ-12 | 160 | 50 | 6 | 30.7 | 37 | ||
| 125CLZⅡ-12A | 150 | 46 | 6 | 26.5 | 30 | ||
| 125CLZⅡ-8 | 160 | 80 | 6 | 58.1 | 75 | ||
| 125CLZⅡ-8A | 150 | 75 | 6 | 51 | 75 | ||
| 125CLZⅡ-8B | 150 | 68 | 6 | 47.1 | 55 | ||
| 125CLZⅡ-13 | 200 | 50 | 6 | 38.34 | 45 | ||
| 型號 |
電壓380伏 380V 頻率50Hz 50Hz |
||||||
|---|---|---|---|---|---|---|---|
|
泵的主要性能參數 |
|||||||
| 流量 m3/h | 揚程 m | 轉速 r/min | 汽蝕余量 m | 軸功率 kW | 配用功率 kW | 單泵重量 Kg | |
| 125CLZⅡ-13A | 185 | 45 | 6 | 31.9 | 37 | ||
| 125CLZⅡ-9 | 200 | 80 | 6 | 70.3 | 90 | ||
| 125CLZⅡ-9A | 180 | 72 | 6 | 57 | 75 | ||
| 125CLZⅡ-7 | 200 | 125 | 6 | 109.77 | 132 | ||
| 125CLZⅡ-7A | 190 | 112.8 | 6 | 94.1 | 110 | ||
| 125CLZⅡ-7B | 180.5 | 101.8 | 6 | 82 | 110 | ||
| 150CLZⅡ-10 | 265 | 86 | 5.5 | 100.1 | 132 | ||
| 150CLZⅡ-10A | 251 | 77 | 5.5 | 84.86 | 110 | ||
| 200CLZⅡ-11.5 | 300 | 32 | 5 | 43.6 | 55 | ||
| 200CLZⅡ-11.5A | 282 | 28.3 | 5 | 36.8 | 45 | ||
| 200CLZⅡ-11.5B | 264 | 24.8 | 5 | 30.73 | 37 | ||
| 200CLZⅡ-24.5 | 450 | 15 | 6 | 29.2 | 37 | ||
| 200CLZⅡ-24.5A | 418 | 13 | 6 | 23.86 | 30 | ||
| 200CLZⅡ-10 | 400 | 45 | 5.2 | 75.4 | 90 | ||
| 200CLZⅡ-10A | 380 | 41 | 5.2 | 66.27 | 90 | ||
| 200CLZⅡ-10B | 340 | 32.5 | 5.2 | 47 | 55 | ||
| 250CLZⅡ-16 | 500 | 28 | 5.5 | 63.5 | 75 | ||
| 250CLZⅡ-16A | 475 | 25.3 | 5.5 | 55.45 | 75 | ||
| 型號 |
電壓440伏 440V 頻率60Hz 60Hz |
||||||
|---|---|---|---|---|---|---|---|
|
泵的主要性能參數 |
|||||||
| 流量 m3/h | 揚程 m | 轉速 r/min | 汽蝕余量 m | 軸功率 kW | 配用功率 kW | 單泵重量 Kg | |
| 40CLZⅡ1-2 | 6 | 87.4 | 3500 | 4 | 7.93 | 11 | |
| 40CLZⅡ1-2A | 4.8 | 77.7 | 4 | 5.64 | 7.5 | ||
| 40CLZⅡ1-2B | 4.8 | 54.7 | 4 | 3.97 | 5.5 | ||
| 50CLZⅡ1-4.5 | 15 | 46 | 4.4 | 4.7 | 5.5 | ||
| 50CLZⅡ1-4.5A | 13.4 | 37.4 | 4.4 | 3.41 | 5.5 | ||
| 50CLZⅡ1-4.5B | 12 | 40.3 | 4.4 | 3.3 | 4 | ||
| 50CLZⅡ1-4.5C | 12 | 29.5 | 4.4 | 2.41 | 3 | ||
| 50CLZⅡ1-6 | 24.1 | 46.6 | 4.4 | 6.24 | 7.5 | ||
| 50CLZⅡ1-6A | 20.4 | 40.3 | 4.4 | 4.57 | 5.5 | ||
| 50CLZⅡ1-9 | 32.6 | 21.1 | 4.4 | 3.29 | 5.5 | ||
| 50CLZⅡ1-9A | 25.2 | 17.3 | 4.4 | 2.16 | 3 | ||
| 50CLZⅡ1-7 | 15 | 29.1 | 4.4 | 2.33 | 4 | ||
| 50CLZⅡ1-7A | 12 | 24.5 | 4.4 | 1.57 | 2.2 | ||
| 50CLZⅡ1-7B | 12 | 20.1 | 4.4 | 1.31 | 2.2 | ||
| 50CLZⅡ1-3 | 15 | 72 | 4.4 | 8.4 | 11 | ||
| 50CLZⅡ1-3A | 12 | 64.8 | 4.4 | 6.1 | 7.5 | ||
| 50CLZⅡ1-3B | 12 | 46 | 4.4 | 4.3 | 5.5 | ||
| 50CLZⅡ1-4 | 24 | 72 | 4.4 | 11.2 | 15 | ||
| 50CLZⅡ1-4A | 20.4 | 66.2 | 4.4 | 8.8 | 11 | ||
| 50CLZⅡ1-4B | 20.4 | 51.8 | 4.4 | 6.85 | 11 | ||
| 65CLZⅡ1-9 | 30.2 | 29.1 | 4.4 | 3.9 | 5.5 | ||
| 65CLZⅡ1-9A | 25.2 | 24.5 | 4.4 | 2.8 | 4 | ||
| 65CLZⅡ1-6 | 30.2 | 46.6 | 4.4 | 7.5 | 11 | ||
| 65CLZⅡ1-6A | 27.5 | 39 | 4.5 | 5.72 | 7.5 | ||
| 65CLZⅡ1-6B | 25.2 | 40.3 | 4.5 | 5.42 | 7.5 | ||
| 65CLZⅡ1-5 | 30.2 | 65.6 | 4.5 | 11.47 | 15 | ||
| 65CLZⅡ1-5A | 27 | 52.5 | 4.5 | 8.2 | 11 | ||
| 65CLZⅡ1-4.5 | 30.2 | 87.4 | 4.4 | 16.3 | 22 | ||
| 65CLZⅡ1-4.5A | 26.4 | 77.7 | 4.4 | 12.7 | 15 | ||
| 65CLZⅡ1-4.5B | 24 | 54.7 | 4.6 | 8.12 | 11 | ||
| 型號 |
電壓440伏 440V 頻率60Hz 60Hz |
||||||
|---|---|---|---|---|---|---|---|
|
泵的主要性能參數 |
|||||||
| 流量 m3/h | 揚程 m | 轉速 r/min | 汽蝕余量 m | 軸功率 kW | 配用功率 kW | 單泵重量 Kg | |
| 65CLZⅡ1-3 | 30 | 115 | 3500 | 4.9 | 26.8 | 30 | |
| 65CLZⅡ1-3A | 26.4 | 108 | 4.9 | 22.2 | 30 | ||
| 65CLZⅡ1-3B | 24 | 73.4 | 4.9 | 13.7 | 18.5 | ||
| 65CLZⅡ1-8 | 42 | 46 | 5.5 | 9.6 | 11 | ||
| 65CLZⅡ1-8A | 38.4 | 40.3 | 5.5 | 7.66 | 11 | ||
| 65CLZⅡ1-5.5 | 42 | 70 | 4.9 | 15.1 | 18.5 | ||
| 65CLZⅡ1-5.5A | 27.3 | 56 | 4.9 | 8 | 11 | ||
| 80CLZⅡ1-13 | 54.3 | 30.6 | 5.4 | 7.8 | 11 | ||
| 80CLZⅡ1-13A | 48 | 25.9 | 5.4 | 5.94 | 7.5 | ||
| 80CLZⅡ1-9 | 60 | 46 | 5.5 | 12.5 | 15 | ||
| 80CLZⅡ1-9A | 54 | 37 | 5.5 | 9.4 | 11 | ||
| 80CLZⅡ1-6 | 60.3 | 72.9 | 5.6 | 20.8 | 30 | ||
| 80CLZⅡ1-6A | 54 | 69 | 5.6 | 18.1 | 22 | ||
| 80CLZⅡ1-6B | 54 | 57.6 | 5.6 | 15.1 | 18.5 | ||
| 80CLZⅡ1-7.5 | 72.4 | 72.9 | 4.9 | 25.2 | 30 | ||
| 80CLZⅡ1-7.5A | 66 | 67.7 | 4.9 | 21.7 | 30 | ||
| 80CLZⅡ1-5.5 | 54.3 | 90.3 | 4.9 | 25.2 | 30 | ||
| 80CLZⅡ1-5.5A | 48 | 83.5 | 4.9 | 20.6 | 30 | ||
| 80CLZⅡ1-5.5B | 48 | 72 | 4.9 | 17.75 | 22 | ||
| 80CLZⅡ1-5 | 72.4 | 116.6 | 5.2 | 43.1 | 55 | ||
| 80CLZⅡ1-5A | 68.4 | 103.7 | 5.2 | 35.8 | 45 | ||
| 80CLZⅡ1-5B | 64.8 | 93.4 | 5.2 | 31.1 | 37 | ||
| 80CLZⅡ1-3 | 60.3 | 174.8 | 4.9 | 63.79 | 75 | ||
| 80CLZⅡ1-3A | 54 | 158 | 4.9 | 51.6 | 75 | ||
| 80CLZⅡ1-3B | 51 | 125.2 | 4.9 | 38.63 | 45 | ||
| 100CLZⅡ1-17 | 96.5 | 29 | 4.5 | 11.9 | 15 | ||
| 100CLZⅡ1-17A | 86.4 | 25.9 | 4.5 | 9.83 | 15 | ||
| 100CLZⅡ1-12 | 96.5 | 46.6 | 4.8 | 18.8 | 22 | ||
| 100CLZⅡ1-12A | 86 | 40.3 | 4.8 | 14.74 | 18.5 | ||
| 100CLZⅡ1-8 | 96.6 | 72.9 | 5.2 | 32.5 | 37 | ||
| 型號 |
電壓440伏 440V 頻率60Hz 60Hz |
||||||
|---|---|---|---|---|---|---|---|
|
泵的主要性能參數 |
|||||||
| 流量 m3/h | 揚程 m | 轉速 r/min | 汽蝕余量 m | 軸功率 kW | 配用功率 kW | 單泵重量 Kg | |
| 100CLZⅡ1-8A | 86 | 66 | 3500 | 5.2 | 26.64 | 37 | |
| 100CLZⅡ1-6 | 96.5 | 116.5 | 5 | 57.74 | 75 | ||
| 100CLZⅡ1-6A | 86 | 108 | 5 | 49.58 | 55 | ||
| 100CLZⅡ1-18.5 | 120.7 | 29 | 5 | 14.44 | 18.5 | ||
| 100CLZⅡ1-18.5A | 114 | 25.9 | 5 | 12.56 | 15 | ||
| 100CLZⅡ1-13 | 120.7 | 46.6 | 5 | 21.87 | 30 | ||
| 100CLZⅡ1-13A | 114 | 40 | 5 | 18.25 | 22 | ||
| 100CLZⅡ1-9 | 120.7 | 72.9 | 5.7 | 38.6 | 45 | ||
| 100CLZⅡ1-9A | 114 | 64.8 | 5.7 | 33.52 | 37 | ||
| 100CLZⅡ1-6.5 | 120.7 | 116.5 | 5 | 63.8 | 75 | ||
| 100CLZⅡ1-6.5A | 114 | 108 | 5 | 57.79 | 75 | ||
| 100CLZⅡ1-5 | 120 | 175 | 5 | 114.3 | 132 | ||
| 100CLZⅡ1-5A | 114 | 158 | 5 | 98.1 | 110 | ||
| 100CLZⅡ1-5B | 108 | 139.7 | 5 | 83.8 | 110 | ||
| 125CLZⅡ1-5 | 144.8 | 174.5 | 5.5 | 118.6 | 160 | ||
| 125CLZⅡ1-5A | 136.8 | 155.5 | 5.5 | 99.84 | 132 | ||
| 125CLZⅡ1-5B | 129.6 | 139.6 | 5.5 | 86.4 | 110 | ||
| 125CLZⅡ1-23 | 193 | 29 | 5.2 | 24.57 | 30 | ||
| 125CLZⅡ1-16.5 | 193 | 46.6 | 5.2 | 37.1 | 45 | ||
| 125CLZⅡ1-16.5A | 180 | 40 | 5.2 | 30.63 | 37 | ||
| 125CLZⅡ1-12 | 193 | 72.8 | 6 | 53.87 | 75 | ||
| 125CLZⅡ1-12A | 180 | 66 | 6 | 46.2 | 55 | ||
| 125CLZⅡ1-8 | 193.1 | 116.6 | 6.2 | 102 | 132 | ||
| 125CLZⅡ1-8A | 180 | 108 | 6.2 | 88.2 | 110 | ||
| 125CLZⅡ1-8B | 180 | 98 | 6.2 | 81.39 | 110 | ||
| 125CLZⅡ1-13 | 241.4 | 72.8 | 6 | 67.38 | 75 | ||
| 125CLZⅡ1-13A | 222 | 64.8 | 6 | 55.16 | 75 | ||
| 125CLZⅡ1-9 | 241.4 | 116.6 | 6.4 | 125.6 | 160 | ||
| 125CLZⅡ1-9A | 216 | 103.7 | 6.4 | 100 | 132 | ||
| 125CLZⅡ1-7 | 241 | 182 | 6 | 192.6 | 250 | ||
| 型號 |
電壓440伏 440V 頻率60Hz 60Hz |
||||||
|---|---|---|---|---|---|---|---|
|
泵的主要性能參數 |
|||||||
| 流量 m3/h | 揚程 m | 轉速 r/min | 汽蝕余量 m | 軸功率 kW | 配用功率 kW | 單泵重量 Kg | |
| 125CLZⅡ1-7A | 228 | 162 | 3500 | 6 | 162.17 | 200 | |
| 125CLZⅡ1-7B | 216 | 146.6 | 6 | 141.3 | 160 | ||
| 150CLZⅡ1-10 | 319.8 | 125.5 | 5.5 | 176.2 | 200 | ||
| 150CLZⅡ1-10A | 301 | 110.8 | 5.5 | 146.43 | 200 | ||
| 200CLZⅡ1-11.5 | 362 | 46.7 | 1750 | 5 | 76.7 | 90 | |
| 200CLZⅡ1-11.5A | 338 | 40.7 | 5 | 63.47 | 75 | ||
| 200CLZⅡ1-11.5B | 316.8 | 35.7 | 5 | 53.1 | 75 | ||
| 200CLZⅡ1-24.5 | 543 | 21.9 | 6 | 51.38 | 75 | ||
| 200CLZⅡ1-24.5A | 501 | 18.7 | 6 | 41.13 | 55 | ||
| 200CLZⅡ1-10 | 482 | 65 | 5.2 | 131.2 | 160 | ||
| 200CLZⅡ1-10A | 456 | 59 | 5.2 | 114.44 | 132 | ||
| 200CLZⅡ1-10B | 408 | 46.8 | 5.2 | 81.22 | 110 | ||
| 250CLZⅡ1-16 | 603 | 40.9 | 5.5 | 111.9 | 132 | ||
| 250CLZⅡ1-16A | 570 | 36.4 | 5.5 | 95.73 | 110 | ||
